Bronchoskop

specifications	BF30	BF42	BF45	BF52	BF58	BF62
Field of View	120°	120°	120°	120°	120°	120°
Depth of View Field	3 mm – 200 mm	3 mm – 200 mm	3 mm – 200 mm	3 mm – 200 mm	3 mm – 200 mm	3 mm – 200 mm
Range of Tip Bending	(U) 180° (D) 130°	(U) 180° (D) 130°	(U) 180° (D) 130°	(U) 180° (D) 130°	(U) 180° (D) 130°	(U) 180° (D) 130°
Outer Diameter of Insertion Tube	⌀ 3.0 mm	⌀ 4.2 mm	⌀ 4.5 mm	⌀ 5.2 mm	⌀ 5.8 mm	⌀ 6.2 mm
Inner Diameter of Instrument Channel	⌀ 1.2 mm	⌀ 2.0 mm	⌀ 2.2 mm	⌀ 2.6 mm	⌀ 2.8 mm	⌀ 3.2 mm
Working Length	600 mm	600 mm	600 mm	600 mm	600 mm	600 mm
